ELECTRICAL EQUIPMENT AT ENGINE / ELECTRICAL EQUIPMENT AT ENGINE — Mercedes-Benz TYP 300 188.015: схема и номера деталей | Глав Авто
Запчасти
/
ELECTRICAL EQUIPMENT AT ENGINE / ELECTRICAL EQUIPMENT AT ENGINE
Mercedes-Benz · TYP 300 · 188.015
ELECTRICAL EQUIPMENT AT ENGINE / ELECTRICAL EQUIPMENT AT ENGINE
ELECTRICAL EQUIPMENT AT ENGINE
Детали узла
66
1
STARTER MOTOR WITH FLANGE, MOUNTED ON THE LEFT SIDE
BE900005
code_image=http://www.elcats.ru/Codes.ashx?Key=i4hodB7Gy%2fcfUz9jD0Pgvzh68xMVeU%2fsk8GFnzOtHF0%3d
1 шт
11
GENERATOR
88200006
code_image=http://www.elcats.ru/Codes.ashx?Key=b6o6JGO%2by%2bMLTFLNY9DVk5ohcs7Xydnq6TS3RClwoao%3d
1 шт
13
SET OF CARBON BRUSHES 2 PIECES
57000006
code_image=http://www.elcats.ru/Codes.ashx?Key=b6o6JGO%2by%2bMLTFLNY9DVkyKzOvJyzib0L5PnjpmzyBI%3d
1 шт
14
SPRING FOR CARBON BRUSH
1BF00006
code_image=http://www.elcats.ru/Codes.ashx?Key=b6o6JGO%2by%2bMLTFLNY9DVk5%2fp8Acksn6mk24r4tIPsCI%3d
2 шт
15
REGULATOR SWITCH FOR GENERATOR AT DASHBOARD SEE ALSO GROUP 54
5A000006
code_image=http://www.elcats.ru/Codes.ashx?Key=b6o6JGO%2by%2bMLTFLNY9DVkyfemraignNjIRQwE2Ktvjs%3d
1 шт
16
PULLEY FOR GENERATOR
60B00142
code_image=http://www.elcats.ru/Codes.ashx?Key=4RgLBD2D7dlwdwpMFeM5yyu7EcCUSCyqGhEE3afOrAM%3d
1 шт
2
FREE-WHEEL UNIT, ROLLER WITH PINION, 9 TEETH AND SPRING
30A00005
code_image=http://www.elcats.ru/Codes.ashx?Key=i4hodB7Gy%2fcfUz9jD0Pgv9w%2bUh4jGM91aD85tGaKldk%3d
1 шт
20
SUPPORT FOR GENERATOR
46400142
code_image=http://www.elcats.ru/Codes.ashx?Key=4RgLBD2D7dlwdwpMFeM5ywbVBH4Vm3DoXoMKh%2fqH7rQ%3d
1 шт
23
COUPLING HALF
4EF00138
code_image=http://www.elcats.ru/Codes.ashx?Key=z4r1wePzzx8J2zhZ7kOiOgw6SM4HCaqViTAYvHuJADM%3d
1 шт
24
WEDGE-TYPE SCREW FOR COUPLING HALF
31D00139
code_image=http://www.elcats.ru/Codes.ashx?Key=WzK7yJEssf2oawObBWhYqPUUNxklQslcVwyp%2bOXpkac%3d
1 шт
27
FOLLOWER RING
4F200138
code_image=http://www.elcats.ru/Codes.ashx?Key=z4r1wePzzx8J2zhZ7kOiOvpjGF30lqASeNU6fH%2bNVoo%3d
1 шт
29
TIGHTENING STRAP FOR GENERATOR
34800138
code_image=http://www.elcats.ru/Codes.ashx?Key=A%2bkoTFAW9Q8CE6hDigRvtFlDVIhsEEwBlp8iqgqUViU%3d
1 шт
3
SET OF CARBON BRUSHES 4 PIECES
50B00005
code_image=http://www.elcats.ru/Codes.ashx?Key=i4hodB7Gy%2fcfUz9jD0Pgv0HhQtQseORTsucm4O5AJ60%3d
1 шт
31
COLLAR SCREW
42600138
code_image=http://www.elcats.ru/Codes.ashx?Key=z4r1wePzzx8J2zhZ7kOiOkkdig%2fl1IllYFr5d5T9gnU%3d
1 шт
32
IGNITION DISTRIBUTOR WITH COUPLING
49A00142
code_image=http://www.elcats.ru/Codes.ashx?Key=Ac%2bB3qC2kgTP9SatjAuonjGwn9%2f8eD2%2bTYyhPHa4ycM%3d
1 шт
33
DISTRIBUTOR PLATE WITH CARBON BRUSH
DDA00006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rfTz%2bSlPi%2bM8qGbmt3ZBJYY%3d
1 шт
34
CARBON BRUSH WITH SPRING
E0D00006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rXGeXzq6T934oWnDmDDISYs%3d
1 шт
35
OILER
21D00008
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rQ0gnlaG8EsM4morsFA6Y28%3d
1 шт
36
CONTACT BREAKER ARM WITH CONTACT
4A200008
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rQGwtz%2b1NgQ2toE8xlVxgqQ%3d
1 шт
37
CONTACT CARRIER
EDF00006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rQYVtyKiZCKTYPO9Yx8H4sY%3d
1 шт
38
IGNITION DISTRIBUTOR ROTOR
15E00007
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rTVCtpwA4TY3DUyapabMlP4%3d
1 шт
39
LEAF SPRING FOR DISTRIBUTOR CAP
E1900006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rROT7J2jWh%2bHZLn%2b4hgodWo%3d
2 шт
4
SPRING FOR CARBON BRUSH
1B100005
code_image=http://www.elcats.ru/Codes.ashx?Key=i4hodB7Gy%2fcfUz9jD0Pgv84RRBox8uD2rL5faMHNq%2b8%3d
4 шт
40
MOUNTING SHACKLE WITHOUT NOSE FOR LEAF SPRING
ED900006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rcU8XexHTbVwkvPRDouNTQ8%3d
1 шт
41
MOUNTING SHACKLE WITH NOSE FOR LEAF SPRING
E5200006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rVY6%2b2jJ4bMAGUXHx1n%2bXmE%3d
1 шт
44
CONDENSER
91500006
code_image=http://www.elcats.ru/Codes.ashx?Key=9YP5ASxj33MqB8rqx0mq45%2fqMTf1uw1m38CHChN54eQ%3d
1 шт
47
VACUUM PRESSURE CONTROLLER, COMPLETE
E3700006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rfEVDU0WafWkFQ1q3xaSxJ8%3d
1 шт
5
SOLENOID SWITCH ON TERMINAL HOUSING
D2400005
code_image=http://www.elcats.ru/Codes.ashx?Key=IhMkB4KFd623XD0olSD5nYWoPrnQqQNhqFeDAQVi%2flU%3d
1 шт
50
COUPLING FOR IGNITION DISTRIBUTOR
E4600006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rSdQAT73TC3amH2rAczvPvk%3d
1 шт
51
FIBER WASHER
D5900006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rbioZ%2bYwb1xztMorm9ajVz8%3d
1 шт
52
SPACER 0.1 MM THICK
E7000006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rVjNxzxFtk5z2SAbHIkwl%2fc%3d
NB шт
53
NOTCHED PIN 4 MM THICK
F3000006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rTvTuAzigBf0uhtd4zGwIVw%3d
1 шт
54
SEAL FOR VACUUM PRESSURE LINE AT VACUUM PRESSURE CONTROLLER
C4A00007
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rYSAjfRot2JfcGJhxh9ZhLw%3d
1 шт
55
THREADED BUSH FOR VACUUM PRESSURE LINE AT VACUUM PRESSURE CONTROLLER
CD500006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rUaQ5CsWMpPA11a8%2fHCz1xk%3d
1 шт
56
BEARING FOR IGNITION DISTRIBUTOR
51500142
code_image=http://www.elcats.ru/Codes.ashx?Key=4RgLBD2D7dlwdwpMFeM5y%2fNwoj9uUK4gh0XcQieVBog%3d
1 шт
57
ADJUSTING LEVER
A7100135
code_image=http://www.elcats.ru/Codes.ashx?Key=upLVDMnGPHck7hnJgwR6Vebe32gAJ6qEcoBpjVbKjaY%3d
1 шт
6
BUSHING IN DRIVE BEARING AND COMMUTATOR BEARING
1DE00005
code_image=http://www.elcats.ru/Codes.ashx?Key=i4hodB7Gy%2fcfUz9jD0Pgv9mwbcXkofDbbOMR4XRrRwg%3d
2 шт
61
COIL SPRING FOR ADJUSTING LEVER AT BEARING
8CB000EC
code_image=http://www.elcats.ru/Codes.ashx?Key=YGHKYQPbcK8R%2fh0V2kF3gBGu5EVZ%2fCgAcflTjbXhzmw%3d
1 шт
65
PRESSURE SPRING FOR IGNITION ADJUSTMENT AT BEARING
4DC00139
code_image=http://www.elcats.ru/Codes.ashx?Key=D9AAg63CbEh9wVxAXyi%2f0oTbipvGVlLDwVSYB0XXCdQ%3d
1 шт
66
SET SCREW FOR IGNITION ADJUSTMENT AT BEARING
32D00138
code_image=http://www.elcats.ru/Codes.ashx?Key=Ny5G7onM9uRcmPr8h9nSvNCNKVrAefmoa%2bFxAiaOl4I%3d
1 шт
68
RUBBER SLEEVE FOR IGNITION ADJUSTMENT AT BEARING
70E00138
code_image=http://www.elcats.ru/Codes.ashx?Key=Ny5G7onM9uRcmPr8h9nSvCeEwIWusvbSb5pRQVlKzio%3d
1 шт
69
SLEEVE FOR IGNITION ADJUSTMENT AT BEARING
37E0013B
code_image=http://www.elcats.ru/Codes.ashx?Key=Ny5G7onM9uRcmPr8h9nSvP%2b1H6RaJG2SvE5Y0ALr1h4%3d
1 шт
70
DAMPENING RUBBER FOR IGNITION ADJUSTMENT AT BEARING
3840013B
code_image=http://www.elcats.ru/Codes.ashx?Key=Ny5G7onM9uRcmPr8h9nSvP9hNNDLEU7jRmHhpPH80IY%3d
1 шт
72
CLAMPING PIECE
75F00141
code_image=http://www.elcats.ru/Codes.ashx?Key=qyN%2bfHlZAbLrRZiuDM4Ifak3vOaeZigYe0w%2fYKiXYQg%3d
1 шт
74
BEARING FOR IGNITION DISTRIBUTOR DRIVE
38A00138
code_image=http://www.elcats.ru/Codes.ashx?Key=A%2bkoTFAW9Q8CE6hDigRvtDugxlwlsnw1nUNr8joSCX0%3d
1 шт
75
HELICAL GEAR
72C00138
code_image=http://www.elcats.ru/Codes.ashx?Key=A%2bkoTFAW9Q8CE6hDigRvtPFH2zldDnAyZCKOYttYbWc%3d
1 шт
76
TUBE FOR VACUUM PRESSURE LINE, MIXTURE CONTROLLER
64D00142
code_image=http://www.elcats.ru/Codes.ashx?Key=Ac%2bB3qC2kgTP9SatjAuonnfsE8YsFksefruFLPRvLrY%3d
1 шт
76a
TUBE FOR VACUUM PRESSURE LINE, DISTRIBUTOR
3810013B
code_image=http://www.elcats.ru/Codes.ashx?Key=Ny5G7onM9uRcmPr8h9nSvEe1PNzIKcD%2btLkP%2bLH6Heg%3d
1 шт
79
RUBBER HOSE
6D000137
code_image=http://www.elcats.ru/Codes.ashx?Key=V%2bd3k3E9XZZM3vJGfCyyYkG27XXr80uaDlIZUMRivic%3d
1 шт
80
HOSE STRAP
51B00139
code_image=http://www.elcats.ru/Codes.ashx?Key=V%2bd3k3E9XZZM3vJGfCyyYhKMCm8%2f9p%2bQQ51AbEft49Y%3d
2 шт
81
CLAMP FOR VACUUM PRESSURE LINE AT CYLINDER HEAD
5E400139
code_image=http://www.elcats.ru/Codes.ashx?Key=v%2bHKLg1zjwex4macZD0bYeLxLCSZGDZA4kKx%2bfWp28E%3d
1 шт
84
CLAMP FOR VACUUM PRESSURE LINE AT WATER PIPE, COOLING WATER OUTLET NIPPLE
8EF00146
code_image=http://www.elcats.ru/Codes.ashx?Key=3vBjYKFE1aphytyYqGu6sdvY%2fWXaHwBiwCqiez8UWW4%3d
2 шт
86b
GROUND CABLE FROM TIMING DISTRIBUTOR TO CYLINDER HEAD FROM ENGINE NO. 65 00195
CFB000C7
code_image=http://www.elcats.ru/Codes.ashx?Key=g47dcvINQmkba2b1FfSerrbrJpB5mycsZiJUgIQc2AQ%3d
1 шт
87
IGNITION CABLE HARNESS
D5400140
code_image=http://www.elcats.ru/Codes.ashx?Key=qyN%2bfHlZAbLrRZiuDM4IfTr5mJXltQAcdrUdiyH649g%3d
1 шт
88
IGNITION CABLE PLUG
17C00007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmgwDfBFVwbIHjTh%2bLjsMQVD4%3d
6 шт
89
INTERFERENCE SUPPRESSION
9C300006
code_image=http://www.elcats.ru/Codes.ashx?Key=9YP5ASxj33MqB8rqx0mq46vKXlA%2fhZZ9mXRNsX6RbWI%3d
6 шт
90
RAIN-PROTECTIVE CAP FOR INTERFERENCE SUPPRESSED IGNITION CABLE
60B00007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmg2EolN3CvbXOLHlar3icOdo%3d
7 шт
91
RUBBER GROMMET AT PROTECTIVE TUBE FOR IGNITION CABLE
F390004B
code_image=http://www.elcats.ru/Codes.ashx?Key=c3fAV1yF5G1OIQb1jfh8J3o5bsSp1Rylo5ekWw9kk5E%3d
6 шт
92
INTERFERENCE SUPPRESSION
9C300006
code_image=http://www.elcats.ru/Codes.ashx?Key=9YP5ASxj33MqB8rqx0mq46vKXlA%2fhZZ9mXRNsX6RbWI%3d
1 шт
92
HIGH AND LOW VOLTAGE CABLE
62A00138
code_image=http://www.elcats.ru/Codes.ashx?Key=A%2bkoTFAW9Q8CE6hDigRvtOSm4zmxOighTKSwrBuEHHM%3d
1 шт
93
CABLE SLEEVE
5BD00007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmg1Jq7%2bCQPkdwjttDyw27N%2bE%3d
1 шт
93
RAIN-PROTECTIVE CAP FOR INTERFERENCE SUPPRESSED IGNITION CABLE
60B00007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmg2EolN3CvbXOLHlar3icOdo%3d
1 шт
95
RUBBER GROMMET
45D000F8
code_image=http://www.elcats.ru/Codes.ashx?Key=MAFS1tva%2bOCTsPEp7VC5T9bYxg%2bcXuEl7c3KTpjC0Z8%3d
2 шт
99
SPARK PLUG OPTIONAL
55400007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmg40wFBg3qmkVQ4dEzciYY6U%3d
6 шт
99
SPARK PLUG OPTIONAL
9CB00007
code_image=http://www.elcats.ru/Codes.ashx?Key=oD6YkNI5dPFnZSHGxlAmg47JGHNjAbm0QY%2fKmQHa%2f2s%3d
6 шт
99
IGNITION COIL SEE ALSO GROUP 54
E1F00006
code_image=http://www.elcats.ru/Codes.ashx?Key=t1oOqZBXaEEHVaHs7oy4rSVU7YO7ymZSp8aRPYkPd3Y%3d
1 шт
